Block info
views: Sections
The drawing shows sectional CAD profiles of IPE steel beams in multiple sizes, arranged from smaller to larger sizes. The upper row includes IPE80 through IPE330, while the lower row shows larger sections such as IPE360, IPE400, IPE450, IPE500, IPE550, and IPE600. Each profile is drawn as a simple H-shaped beam cross-section.
